PostSubject: slow up back-up   Sat Mar 27, 2010 2:50 am

share ko lang sa mga hindi pa nakaka encounter

nokia 2330c-2 auto shut off

history:bigla nalang daw nagkaganito

action taken:check ko hindi naman shorted

then check ko sa box eto lumabas

Quote :
Phone Type: RM-512 (Nokia 2330c-2)
SW Version: V 06.46 23-03-09 RM-512 (c) Nokia
Imei plain: 3519490369angel
Product Code: 0586136
Cellular System: GSM
ASIC ID: 0x3168, type: 0
Ppm Id: T
Language Pack:
- not available.


Imei net: 351949036angel
Version: SIMLOCK SERVER
Provider: ALL Operator, Country: -
Counter: 0/3, 0/10

CONFIG_DATA: 0010100000000000
PROFILE_BITS: 800000000003000B

SIMLOCK_DATA corrupted!



then flash kuna sya using version [URL="http://www.sendspace.com/file/42zw0m"]8.02[/URL] uncheck ko lang yung safe flash minsan kase nagkakarun nang error o kaya naman ayaw i detect ang unit(based on my experienced)
flashing





after sa flashing done!

logs

[HTML]
Using device: UFS_USB V2.8 (c) SarasSoft 2007.
Library version: 1.0.0.7687(12-02-2010), 1.0.0.12095(13-02-2010)
Processing file: rm512__08.20.mcusw as MCU
[DCT4,DCT4 ALGORITHM] size: 11.88 MB
Supported Ids: 3160, 3161, 3162, 3164, 3166, 3168
ASIC ID: 0x3168 [UPP_8M ver: 6.4]
SecondaryBoot: u3_2nd.fia [DCT4] version: 4.76.0 revision: 0.7 size: 0x9A8
Supported Ids: 3040, 2292, 2293, 3162, 3166, 3168
FlashID0: 0089 8981 [Intel NU48F256,256 Mbits] page size: 128 K type: NOR area: 01000000-02FFFFFF - COMBO FLASH
ExtBUSC: AD7E B61B 2310 0340 C605 E401 20A2 0000
Algorithm: u3_intel.fia [DCT4 ALGORITHM] version: 4.76.0 revision: 0.7 size: 0x56A0
Supported Ids: 3040, 2292, 2293, 3162, 3166, 3168
Performing Flash Authentication ...OK
UEM ID: 0080011D:3B8ADA60
Area [01000000-0101FFFF] erased in 0.703 s
Area [01020000-01CFFFFF] erased in 1 min 5.563 s
Flash programming ...
Programming completed in 13 min 25.906 s
File Processed in 14 min 42.437 s
Processing file: rm512__08.20.image_x_brown as CNT
[DCT4,DCT4 ALGORITHM] page size: 128 K size: 5.63 MB
Supported Ids: 3160, 3161, 3162, 3164, 3166, 3168
ASIC ID: 0x3168 [UPP_8M ver: 6.4]
SecondaryBoot: u3_2nd.fia [DCT4] version: 4.76.0 revision: 0.7 size: 0x9A8
Supported Ids: 3040, 2292, 2293, 3162, 3166, 3168
FlashID0: 0089 8981 [Intel NU48F256,256 Mbits] page size: 128 K type: NOR area: 01000000-02FFFFFF - COMBO FLASH
ExtBUSC: AD7E B61B 2310 0340 C605 E401 20A2 0000
Algorithm: u3_intel.fia [DCT4 ALGORITHM] version: 4.76.0 revision: 0.7 size: 0x56A0
Supported Ids: 3040, 2292, 2293, 3162, 3166, 3168
Performing Flash Authentication ...OK
UEM ID: 0080011D:C5A4DA78
Area [02180000-02E7FFFF] erased in 1 min 40.125 s
Area [02E80000-02FBFFFF] erased in 9.531 s
Converting UCP blocks to 128 K.
Flash programming ...
Programming completed in 6 min 13.282 s
Extract fail, service not ready?
Content extract fail, continue anyway ...
File Processed in 8 min 24.719 s
Processing file: rm512__08.20.ppm_x as PPM
[DCT4,DCT4 ALGORITHM] size: 2.80 MB
Supported Ids: 3160, 3161, 3162, 3164, 3166, 3168
ASIC ID: 0x3168 [UPP_8M ver: 6.4]
SecondaryBoot: u3_2nd.fia [DCT4] version: 4.76.0 revision: 0.7 size: 0x9A8
Supported Ids: 3040, 2292, 2293, 3162, 3166, 3168
FlashID0: 0089 8981 [Intel NU48F256,256 Mbits] page size: 128 K type: NOR area: 01000000-02FFFFFF - COMBO FLASH
ExtBUSC: AD7E B61B 2310 0340 C605 E401 20A2 0000
Algorithm: u3_intel.fia [DCT4 ALGORITHM] version: 4.76.0 revision: 0.7 size: 0x56A0
Supported Ids: 3040, 2292, 2293, 3162, 3166, 3168
Performing Flash Authentication ...OK
UEM ID: 0080011D:2984DA60
Area [01D00000-0217FFFF] erased in 14.625 s
Flash programming ...
Programming completed in 2 min 59.343 s
File Processed in 3 min 21.562 s
Flashing completed in 26 min 28.782 s


Phone Type: RM-512 (Nokia 2330c-2)
SW Version: V 08.20 30-06-09 RM-512 (c) Nokia
Imei plain: 3519490369angel
Imei OTP: 351949036angel
Product Code: 0586136
Cellular System: GSM
ASIC ID: 0x3168, type: 11
Ppm Id: X
Language Pack:
- not available.


Imei net: 351949036angel
Version: SIMLOCK SERVER
Provider: ALL Operator, Country: -
Counter: 0/3, 0/10

CONFIG_DATA: 0010100000000000
PROFILE_BITS: 800000000003000B

BLOCK 1: 1.OPEN 2.OPEN 3.OPEN 4.OPEN 5.OPEN
BLOCK 2: 1.OPEN 2.OPEN 3.OPEN 4.OPEN 5.OPEN
BLOCK 3: 1.OPEN 2.OPEN 3.OPEN 4.OPEN 5.OPEN
BLOCK 4: 1.OPEN 2.OPEN 3.OPEN 4.OPEN 5.OPEN
BLOCK 5: 1.OPEN 2.OPEN 3.OPEN 4.OPEN 5.OPEN
BLOCK 6: 1.OPEN 2.OPEN 3.OPEN 4.OPEN 5.OPEN
BLOCK 7: 1.OPEN 2.OPEN 3.OPEN 4.OPEN 5.OPEN
Total time to process is 26 min 44.782 s
[/HTML]
Back to top Go down
View user profile
slow up
UnLoCkit V.I.P
UnLoCkit V.I.P


Number of posts : 58
Registration date : 2010-03-27

PostSubject: Re: slow up back-up   Sat Mar 27, 2010 2:51 am

share ko lang gawa ko ngayun

nokia 6300 kusa daw syang namamatay sa loob nang 30 minutos

naka ilang palit na din syang battery

action taken:check ko memory card nya

at tignan nyo kung anu na find out ko

puno nang virus ang memory card



kaya flash ko ang unit



done

logs
Quote :
JAF version 1.98.65
Detected PKEY: slowdown_247
P-key nokia module version 01.02
Detected JAF INTERFACE version: 01.B4, Driver version: 40000, Library version: 30107
JAF DCT4/BB5 LOADERS DIR: C:\Program Files\ODEON\JAF\Flash\
JAF DCT4/BB5 PRODUCT DIR: C:\Program Files\Nokia\Phoenix\Products\
JAF USB LOADERS DIR: C:\Program Files\ODEON\JAF\FlashUSB\
JAF DCT3/DCTL LOADERS DIR: C:\Program Files\ODEON\JAF\Flash3\
USB Cable Driver version: 7.0.2.0
Changing mode...Done!
Booting phone...

CMT Boot Data:
Asic ID: 000000010000022600010006010C192101001101
Asic Mode ID: 00
Asic EM ID: 00000353
Asic Public ID: 21C0000A1B1E6E56C74DA6ECE75CB319377A910E
HASH: BAF3A9C3DBFA8454937DB77F2B8852B100000000
ROM ID: 191EC665DFAAF68F
CMT Boot File: C:\Program Files\ODEON\JAF\Flash\rap3gv3_2nd.fg
Loader version: 09.0B.01 -> Revision: 0000
Patching CMT boot step1...
Patching CMT boot step2...
Patching CMT boot step3...
CMT Boot Ready
CMT Flash ID: 220800EC <=> SAMSUNG (SEC) -> K8F5615ETM/K5G5629ATD
CMT Flash Data: 00000000000000000000000000000000
CMT Loader: C:\Program Files\ODEON\JAF\Flash\RAP3Gv3_algo.fg
Loader version: 09.2F.00 -> Revision: 0000
Patching CMT loader step1...
Patching CMT loader step3...
CMT Loader Ready
Done!
Restarting phone...Done!
FILES SET FOR FLASHING:
MCU Flash file: NONE
PPM Flash file: NONE
CNT Flash file: NONE
APE Variant file: NONE
Switching to serial...
Powering the phone...
Reading...
MCU SW version: V 05.00
27-04-07
RM-217
(c) Nokia.
HW version: 4002
PCI version:
RFIC version: 17211721
DSP version: pb06w14v51
PPM version: V 05.00
27-04-07
RM-217
(c) Nokia.
T
BT MCM version: 06cc-P9.1
Retu version: 32
Tahvo version: 53
Content Pack version: Content: t_ph_white
V 05.00
09-05-07
RM-217
(c) Nokia.

Production serial number: 7I0790591
Product code: 0554294
Module code: 0203166
Basic production code: 0551450
Flash code:
Order number:
Product specific data:
Long production SN:
ATO:
Default SN type:
IMEI plain: 3595slowdown_247
IMEI spare to net: 3A 95 slowup
IMEI SV to net: 33 95 slowup

LOCK STATUS:

CONFIG KEY: 0000000000000000
PROVIDER KEY: 2440700000000000
Provider: AT&T;U.S.A. (3650)
Key Code count: 0, FBUS Code count: 0

Block 1:
Lock 1: OPEN Lock 2: OPEN Lock 3: OPEN Lock 4: OPEN Lock 5: OPEN
Block 2:
Lock 1: OPEN Lock 2: OPEN Lock 3: OPEN Lock 4: OPEN Lock 5: OPEN
Block 3:
Lock 1: OPEN Lock 2: OPEN Lock 3: OPEN Lock 4: OPEN Lock 5: OPEN
Block 4:
Lock 1: OPEN Lock 2: OPEN Lock 3: OPEN Lock 4: OPEN Lock 5: OPEN
Block 5:
Lock 1: OPEN Lock 2: OPEN Lock 3: OPEN Lock 4: OPEN Lock 5: OPEN
Block 6:
Lock 1: OPEN Lock 2: OPEN Lock 3: OPEN Lock 4: OPEN Lock 5: OPEN
Block 7:
Lock 1: OPEN Lock 2: OPEN Lock 3: OPEN Lock 4: OPEN Lock 5: OPEN

Searching for saved ini...
Checking for file C:\Program Files\ODEON\JAF\JAF_RM-217.ini
Saved INI not found, loading INI list...
Setting local mode...
Reading product code...
Product Code: 0554294
Searching for JAF saved location of ini...
Checking path: C:\Program Files\Nokia\Phoenix\Products\RM-217\

Searching for default location of ini...
Checking path: \Products\RM-217\
Searching for JAF saved location of ini...
Checking path: C:\Program Files\Nokia\Phoenix\Products\RM-217\
Scanning ini files...
Searching for default location of ini...
Checking path: \Products\RM-217\
Checking path: C:\Program Files\Nokia\Phoenix\Products\RM-217\
FILES SET FOR FLASHING:
MCU Flash file: C:\Program Files\Nokia\Phoenix\Products\RM-217\rm217__07.21.mcusw
PPM Flash file: C:\Program Files\Nokia\Phoenix\Products\RM-217\rm217__07.21.ppm_t
CNT Flash file: C:\Program Files\Nokia\Phoenix\Products\RM-217\rm217__07.21.image_t_ph_white
APE Variant file: NONE
Languages in ppm: English,Vietnamese,Tagalog,Chinese Simpl,Chinese Trad
Done!
Changing flashing settings...
Setting local mode...
Reading...
Searching for default location of ini...
Checking path: \Products\RM-217\
Checking path: C:\Program Files\Nokia\Phoenix\Products\RM-217\
Languages in ppm: English,Thai,Chinese Simpl,Chinese Trad
Changing flashing settings...
Setting local mode...
Reading...
Searching for default location of ini...
Checking path: \Products\RM-217\
Checking path: C:\Program Files\Nokia\Phoenix\Products\RM-217\
FILES SET FOR FLASHING:
MCU Flash file: C:\Program Files\Nokia\Phoenix\Products\RM-217\rm217__07.21.mcusw
PPM Flash file: C:\Program Files\Nokia\Phoenix\Products\RM-217\rm217__07.21.ppm_t
CNT Flash file: C:\Program Files\Nokia\Phoenix\Products\RM-217\rm217__07.21.image_t_ph_white
APE Variant file: NONE
Languages in ppm: English,Vietnamese,Tagalog,Chinese Simpl,Chinese Trad
Backing up CRT data...
Setting FLASH MODE
Loader version: 09.0B.01 -> Revision: 0000
Patching CMT boot step1...
Patching CMT boot step2...
Patching CMT boot step3...
CMT Boot Ready
CMT Flash ID: 220800EC <=> SAMSUNG (SEC) -> K8F5615ETM/K5G5629ATD
CMT Flash Data: 00000000000000000000000000000000
CMT Loader: C:\Program Files\ODEON\JAF\Flash\RAP3Gv3_algo.fg
Loader version: 09.2F.00 -> Revision: 0000
Patching CMT loader step1...
Patching CMT loader step3...
CMT Loader Ready
Reading CMT NPC certificate...
Reading CMT VARIANT certificate...
VARIANT CRT empty, skip save...
Reading CMT CCC certificate...
Reading CMT HWC certificate...
Saved to C:\Program Files\ODEON\JAF\ProgData\3595slowdown_247_CRT_backup_1328113.rpl
Backup CRT OK!
Backing up SIMLOCK data...
Setting local mode...
Reading IMEI...
C:\Program Files\ODEON\JAF\ProgData\3595slowdown_247_CRT_backup_1330113.pm
Done!
Backup LCK OK!
Reading SW version...05.00
Booting phone...

CMT Boot Data:
Asic ID: 000000010000022600010006010C192101001101
Asic Mode ID: 00
Asic EM ID: 00000353
Asic Public ID: 21C0000A1B1E6E56C74DA6ECE75CB319377A910E
HASH: BAF3A9C3DBFA8454937DB77F2B8852B100000000
ROM ID: 191EC665DFAAF68F
CMT Boot File: C:\Program Files\ODEON\JAF\Flash\rap3gv3_2nd.fg
Loader version: 09.0B.01 -> Revision: 0000
Patching CMT boot step1...
Patching CMT boot step2...
Patching CMT boot step3...
CMT Boot Ready
CMT Flash ID: 220800EC <=> SAMSUNG (SEC) -> K8F5615ETM/K5G5629ATD
CMT Flash Data: 00000000000000000000000000000000
CMT Loader: C:\Program Files\ODEON\JAF\Flash\RAP3Gv3_algo.fg
Loader version: 09.2F.00 -> Revision: 0000
Patching CMT loader step1...
Patching CMT loader step3...
CMT Loader Ready
Operation took 0 minutes 4 seconds...
Sending CRT data...
No convertion block detected or file already converted.
Erasing...
Operation took 0 minutes 43 seconds...
Writing...
Stage 1
Sending CMT HASH for NOLO
Sending CMT HASH for KEYS
Sending CMT HASH for PRIMAPP
Sending CMT HASH for PASUBTOC
Sending CMT PUB KEYS...
Sending CMT HASH for UPDAPP
Sending CMT HASH for DSP0
Sending CMT HASH for MCUSW
Sending CMT HASH for PMM_CONF
Sending CMT HASH for SBIF_CONF
Operation took 1 minutes 44 seconds...
Reseting phone...
PPM: C:\Program Files\Nokia\Phoenix\Products\RM-217\rm217__07.21.ppm_t

Booting phone...

CMT Boot Data:
Asic ID: 000000010000022600010006010C192101001101
Asic Mode ID: 00
Asic EM ID: 00000353
Asic Public ID: 21C0000A1B1E6E56C74DA6ECE75CB319377A910E
HASH: BAF3A9C3DBFA8454937DB77F2B8852B100000000
ROM ID: 191EC665DFAAF68F
CMT Boot File: C:\Program Files\ODEON\JAF\Flash\rap3gv3_2nd.fg
Loader version: 09.0B.01 -> Revision: 0000
Patching CMT boot step1...
Patching CMT boot step2...
Patching CMT boot step3...
CMT Boot Ready
CMT Flash ID: 220800EC <=> SAMSUNG (SEC) -> K8F5615ETM/K5G5629ATD
CMT Flash Data: 00000000000000000000000000000000
CMT Loader: C:\Program Files\ODEON\JAF\Flash\RAP3Gv3_algo.fg
Loader version: 09.2F.00 -> Revision: 0000
Patching CMT loader step1...
Patching CMT loader step3...
CMT Loader Ready
Operation took 0 minutes 4 seconds...
No convertion block detected or file already converted.
Erasing...
Operation took 0 minutes 14 seconds...
Writing...
Stage 1
Operation took 0 minutes 35 seconds...
Reseting phone...
CNT: C:\Program Files\Nokia\Phoenix\Products\RM-217\rm217__07.21.image_t_ph_white

Booting phone...

CMT Boot Data:
Asic ID: 000000010000022600010006010C192101001101
Asic Mode ID: 00
Asic EM ID: 00000353
Asic Public ID: 21C0000A1B1E6E56C74DA6ECE75CB319377A910E
HASH: BAF3A9C3DBFA8454937DB77F2B8852B100000000
ROM ID: 191EC665DFAAF68F
CMT Boot File: C:\Program Files\ODEON\JAF\Flash\rap3gv3_2nd.fg
Loader version: 09.0B.01 -> Revision: 0000
Patching CMT boot step1...
Patching CMT boot step2...
Patching CMT boot step3...
CMT Boot Ready
CMT Flash ID: 220800EC <=> SAMSUNG (SEC) -> K8F5615ETM/K5G5629ATD
CMT Flash Data: 00000000000000000000000000000000
CMT Loader: C:\Program Files\ODEON\JAF\Flash\RAP3Gv3_algo.fg
Loader version: 09.2F.00 -> Revision: 0000
Patching CMT loader step1...
Patching CMT loader step3...
CMT Loader Ready
Operation took 0 minutes 4 seconds...
Erasing...
Operation took 0 minutes 28 seconds...
Writing...
Writing converted flash to 128k page
Operation took 0 minutes 43 seconds...
Reseting phone...
Done!
Total time: 4 Minutes, 42 Seconds

DCT4/BB5 counter: 211
After flash processing...
Waiting for phone to boot...
Reading...
Phone type: RM-217, Software version: 07.21
IMEI: 3595slowdown_247
APE Ver: (null)
Variant Ver: (null)
Product Code: 0554294
Done!

observing within 1 hour



job well done

ok na ang unit at hindi na sya namamatay

Wink
Back to top Go down
View user profile
balbon



Number of posts : 1
Registration date : 2008-08-07

PostSubject: Re: slow up back-up   Sat Mar 27, 2010 2:55 am

bilis naman nito nakaback up na agad
Back to top Go down
View user profile
slow up
UnLoCkit V.I.P
UnLoCkit V.I.P


Number of posts : 58
Registration date : 2010-03-27

PostSubject: Re: slow up back-up   Sat Mar 27, 2010 3:01 am

hay sa wakas nag ka buena mano din ako

nokia 6120c lock to globe

procedures:open mxkey
:use jaf interface or ufs then connect
:click option
:open nokia service tool
:click service
:go to imei & security
:click simlock
:click unlock by code
:then click CALC

unlocking done!

logs
Quote :
Imei net: 3598slowdown_247
Version: SIMLOCK SERVER
Provider: Globe Telecom, Country: Philippines
Counter: 0/3, 0/10

CONFIG_DATA: 5150200000000000
PROFILE_BITS: 0000000000000000

BLOCK 1: 1=LOCKED (MCC+MNC): 51502F, DATA=51502F
BLOCK 2: 1=LOCKED (MCC+MNC): 51502F, DATA=51502F


Backup saved to "BB5_3598slowdown_247_SIMLOCK.back"
Using device: UFS_USB V2.8 (c) SarasSoft 2007.
Library version: 1.0.0.7687(12-02-2010), 1.0.0.12095(13-02-2010)

Product: V 03.83 18-06-07 RM-243 (c) Nokia
ApeCoreSw: 03.83

SYSTEM ASIC ID: 000000010000022600010006400C192101021103 [RAPIDO3G ver: 1.11]
ROOT KEY HASH: CAEEBB65D3C48E6DC73B49DC5063A2EE
ROM ID: A8C1D6713E691FF8

Calculating NCK using security server ...
Connecting to server[main.mxkey.biz] ...OK, secure login ...

#pw+ 912788430240964 +1 #
#pw+ 554440704625527 +2 #
#pw+ 721542920956202 +3 #
#pw+ 416341169957401 +4 #
#pw+ 880954545221429 +5 #
#pw+ 921926116472751 +6 #
#pw+ 243921311371270 +7 #

Sending NCK code ...
Trying NCK lock 7 ... OK: code accepted.
Completed in 18.313 s

Restarting phone ...

Reading Simlock info ...
Imei net: 359807012628413
Version: SIMLOCK SERVER
Provider: Globe Telecom, Country: Philippines
Counter: 0/3, 0/10

CONFIG_DATA: 5150200000000000
PROFILE_BITS: 0000000000000000

BLOCK 1: 1=OPEN, DATA=51502F
BLOCK 2: 1=OPEN, DATA=51502F

screenshot



happy unlocking:D

Wink
Back to top Go down
View user profile
slow up
UnLoCkit V.I.P
UnLoCkit V.I.P


Number of posts : 58
Registration date : 2010-03-27

PostSubject: Re: slow up back-up   Sat Mar 27, 2010 3:01 am

share ko lang po itong gawa ko ngayun 1661-2

lalo na sa mga nagsasabing hindi daw nag coconnect mga unit sa mxkey version 3.3. 1.6

history:bigla nalang daw namatay

action taken:basic steps muna po syempre

1st:check ko sa box kung mag coconnect sya

hayun nag connect naman screenshot!..smooth ang connecting;))Wink)



2nd step:program kuna using mxkey

syempre lagyan muna nang flashfiles as shown below tapos narin na flash;)WinkWink




logs

Quote :
Using device: J.A.F, FW ver: 01.B2
Library version: 1.0.0.7687(12-02-2010), 1.0.0.12095(13-02-2010)
Processing file: rh122_004.300 as MCU
[DCT4,DCT4 ALGORITHM] size: 2.38 MB
Supported Ids: 2293
ASIC ID: 0x2293 [UPPCosto ver: 2.0]
SecondaryBoot: u3_2nd.fia [DCT4] version: 4.76.0 revision: 0.7 size: 0x9A8
Supported Ids: 3040, 2292, 2293, 3162, 3166, 3168
FlashID0: 00EC 2254 [Samsung ] page size: 64 K type: NOR area: 01000000-01FFFFFF
FlashID1: 0000 0001 [unused/removed]
ExtBUSC: AD7E B61A 2310 0340 C605 E401 20A2 6514
Algorithm: u3_amd.fia [DCT4 ALGORITHM] version: 4.76.0 revision: 0.7 size: 0x78C0
Supported Ids: 3040, 2292, 2293, 3162, 3166, 3168
Performing Flash Authentication ...OK
UEM ID: 002B6328:2984DA60
Area [01000000-0100FFFF] erased in 0.360 s
Area [01010000-0179FFFF] erased in 42.906 s
Area [017A0000-017EFFFF] erased in 1.781 s
Area [01F00000-01FDFFFF] erased in 0.188 s
Flash programming ...
Programming completed in 17.000 s
File Processed in 1 min 20.422 s
Processing file: rh1220_nai04.30ej as CNT
[DCT4,DCT4 ALGORITHM] size: 175.91 KB
Supported Ids: 2293
ASIC ID: 0x2293 [UPPCosto ver: 2.0]
SecondaryBoot: u3_2nd.fia [DCT4] version: 4.76.0 revision: 0.7 size: 0x9A8
Supported Ids: 3040, 2292, 2293, 3162, 3166, 3168
FlashID0: 00EC 2254 [Samsung ] page size: 64 K type: NOR area: 01000000-01FFFFFF
FlashID1: 0000 0001 [unused/removed]
ExtBUSC: AD7E B61A 2310 0340 C605 E401 20A2 6514
Algorithm: u3_amd.fia [DCT4 ALGORITHM] version: 4.76.0 revision: 0.7 size: 0x78C0
Supported Ids: 3040, 2292, 2293, 3162, 3166, 3168
Performing Flash Authentication ...OK
UEM ID: 002B6328:2984DA60
Area [01750000-0178FFFF] erased in 1.406 s
Flash programming ...
Programming completed in 1.234 s
Extracting Content Pack, File Server fake reply for CUI phone.
Content Pack extracted successfully in 0.171 s
File Processed in 28.469 s
Processing file: rh122_004.30ej as PPM
[DCT4,DCT4 ALGORITHM] size: 2.72 MB
Supported Ids: 2293
ASIC ID: 0x2293 [UPPCosto ver: 2.0]
SecondaryBoot: u3_2nd.fia [DCT4] version: 4.76.0 revision: 0.7 size: 0x9A8
Supported Ids: 3040, 2292, 2293, 3162, 3166, 3168
FlashID0: 00EC 2254 [Samsung ] page size: 64 K type: NOR area: 01000000-01FFFFFF
FlashID1: 0000 0001 [unused/removed]
ExtBUSC: AD7E B61A 2310 0340 C605 E401 20A2 6514
Algorithm: u3_amd.fia [DCT4 ALGORITHM] version: 4.76.0 revision: 0.7 size: 0x78C0
Supported Ids: 3040, 2292, 2293, 3162, 3166, 3168
Performing Flash Authentication ...Area [01250000-0125FFFF] erased in 0.359 s
Area [01260000-0174FFFF] erased in 27.938 s
Flash programming ...
Programming completed in 19.578 s
File Processed in 1 min 3.687 s
Flashing completed in 2 min 52.969 s


Phone Type: RH-122
SW Version: V 04.30 06-07-09 RH-122 (c) Nokia
Imei plain: 356916xxxxxxxx
Product Code: 0572988
Cellular System: GSM
ASIC ID: 0x2293, type: 11
Ppm Id: EJ
Language Pack:
- not available.


Imei net: 356916xxxxxxxx
Version: SIMLOCK SERVER
Provider: ALL Operator, Country: -
Counter: 0/3, 0/10

CONFIG_DATA: 0010100000000000
PROFILE_BITS: 0000000000030002

BLOCK 1: 1.OPEN 2.OPEN 3.OPEN 4.OPEN 5.OPEN
BLOCK 2: 1.OPEN 2.OPEN 3.OPEN 4.OPEN 5.OPEN
BLOCK 3: 1.OPEN 2.OPEN 3.OPEN 4.OPEN 5.OPEN
BLOCK 4: 1.OPEN 2.OPEN 3.OPEN 4.OPEN 5.OPEN
BLOCK 5: 1.OPEN 2.OPEN 3.OPEN 4.OPEN 5.OPEN
BLOCK 6: 1.OPEN 2.OPEN 3.OPEN 4.OPEN 5.OPEN
BLOCK 7: 1.OPEN 2.OPEN 3.OPEN 4.OPEN 5.OPEN
Total time to process is 3 min 10.438 s


job well done!sorry walang screenshot nang unit

wala kase akong pang captured;)WinkWink
Back to top Go down
View user profile
slow up
UnLoCkit V.I.P
UnLoCkit V.I.P


Number of posts : 58
Registration date : 2010-03-27

PostSubject: Re: slow up back-up   Sat Mar 27, 2010 3:02 am

6030b rm-225 unlock and convert

step by step procedures

1st step:flash the unit with version [URL="http://www.sendspace.com/file/e4ml2n"]5.25[/URL]

2nd step:write pm

3rd step:full factory defaults then click unlock

final step:replace two filters and make a jumper

logs:falshing sa version

Quote :
1st Boot: Ok, DCT4, UPP: 2031 [Rm-225] [2.0.9.0]
2nd Boot: u_2nd.fia, Ver: 4.79.0
Fl0: 0x01000000-0x01FFFFFF,00898809,Int 28F128L18
Algorithm: u_intel.fia, Ver: 4.80.0
Algorithm Ok, MSID: 841F728505772B415053DB37C9
Decoded MSID: 9EC3BAE9-00CE19B6-A9000000
Encoded FAID: D1B6E982-CCD1D5AD-1B789899
IMAGE: rm225__5.250
Area1: 0x01000000-0x0101FFFF Erased, Time: 00:00
Area2: 0x01020000-0x017FFFFF Erased, Time: 01:00
Area3: 0x01E60000-0x01FDFFFF Erased, Time: 00:12
MCU Flashing Completed, Time: 06:21
Chip SECTOR_SIZE: 128k, File FAT_SECTOR_SIZE: 64k
Warning, Must be Used 128Kb Sector_Size CNT File
IMAGE: rm225__5.25.image_m_128
Area1: 0x01A00000-0x01E5FFFF Erased, Time: 00:34
CNT Flashing Completed, Time: 01:07
Running: Nokia File Server
CNT Extract Warning, Res: 0, CNT Area not Empty
Contents Package Extracting Ok, Time: 00:07
1st Boot: Ok, DCT4, UPP: 2031 [Rm-225] [2.0.9.0]
2nd Boot: u_2nd.fia, Ver: 4.79.0
Fl0: 0x01000000-0x01FFFFFF,00898809,Int 28F128L18
Algorithm: u_intel.fia, Ver: 4.80.0
Algorithm Ok, MSID: 8495B40FAA9D51C3C4511784EB
Decoded MSID: 3E4EBAE9-00CE19B6-AA000000
Encoded FAID: AAE63001-6495E26D-50E94D3D
IMAGE: rm225__5.25m
Area1: 0x01800000-0x019FFFFF Erased, Time: 00:15
PPM Flashing Completed, Time: 00:56
Flashing Completed, Rebooting Mobile

then write [URL="http://www.sendspace.com/file/5gssmt"]PM[/URL]



THEN UI DEFAULTS


UI Defaults Ok, Time: 00:05
Set UI Factory Defaults Ok, Time: 00:00
Set Full Factory Defaults Ok, Time: 00:00
Set Software Upgrade Defaults Ok, Time: 00:00
Set Security Ok, Time: 00:00
IMEI: 011239-00-646072-0, ASIC: 2
FILE: rm225__5.250
1st Boot: Ok, DCT4, UPP: 2031 [Rm-225] [2.0.9.0]
2nd Boot: u_2nd.fia, Ver: 4.79.0
Fl0: 0x01000000-0x01FFFFFF,00898809,Int 28F128L18
Algorithm: u_intel.fia, Ver: 4.80.0
Algorithm Ok, MSID: 841F728505772B415053DB37C9
Decoded MSID: 9EC3BAE9-00CE19B6-A9000000
Encoded FAID: D1B6E982-CCD1D5AD-1B789899
Area1: 0x010A0000-0x010BFFFF Erased, Time: 00:00
PAT Flashing Completed, Time: 00:06
IMEI: 011239-00-646072-0, ASIC: 2
SimLocks Initialized (Patch Ok), Time: 00:00
1st Boot: Ok, DCT4, UPP: 2031 [Rm-225] [2.0.9.0]
2nd Boot: u_2nd.fia, Ver: 4.79.0
Fl0: 0x01000000-0x01FFFFFF,00898809,Int 28F128L18
Algorithm: u_intel.fia, Ver: 4.80.0
Algorithm Ok, MSID: 841F728505772B415053DB37C9
Decoded MSID: 9EC3BAE9-00CE19B6-A9000000
Encoded FAID: D1B6E982-CCD1D5AD-1B789899
Area1: 0x010A0000-0x010BFFFF Erased, Time: 00:00
UNP Flashing Completed, Time: 00:06
SimLocks Initialized, Time: 00:47

THEN READY TO CONVERT

replace this two filters



and make a jumper like this



job well done!!

sorry diko na picturan ang unit nang mag ok na pagkabayad kase umalis na kaya diko na nakuhanan:(SadSad
Back to top Go down
View user profile
slow up
UnLoCkit V.I.P
UnLoCkit V.I.P


Number of posts : 58
Registration date : 2010-03-27

PostSubject: Re: slow up back-up   Sat Mar 27, 2010 3:03 am

nokia n81 keypad problem

history bumagsak daw....

pina check na daw sa ibang technician at ang sabi eh keypad flex kelangan na daw palitan

action taken so i decided to open the unit and check the line

dito ko naman kinuha ang guide:D:D:D



before



here's the jumper that i applied



after



job well done!

sayang din

800 pesos;))Wink)
Back to top Go down
View user profile
slow up
UnLoCkit V.I.P
UnLoCkit V.I.P


Number of posts : 58
Registration date : 2010-03-27

PostSubject: Re: slow up back-up   Sat Mar 27, 2010 3:04 am

morning po sa lahat ng heroes

share ko lang po sa mga wala pa

new update po ito ng mga bb5 pm files 2010

update ko lang po me wala pa po kase dito

sana magustuhan po ninyo

eto po pala list

[HTML]

Nokia N95 RM-159
Nokia N95 8Gb RM-320
Nokia N93i RM-156
Nokia N91 RM-43 v2
Nokia N91 RM-43 v1
Nokia N90 RM-42
Nokia N82 RM-313
Nokia N81-3 RM-223
Nokia N81-1 8GB RM-179
Nokia N80 RM-92
Nokia N75 RM-128
Nokia N73 RM-133 v2
Nokia N73 RM-133
Nokia N72 RM-180
Nokia N71 RM-67
Nokia N70 RM-84
Nokia E90 RA-6
Nokia E71 RM-346
Nokia E70 RM-10
Nokia E65 RM-208
Nokia E62 RM-88
Nokia E61i RM-227
Nokia E61 RM-89
Nokia E60 RM-49
Nokia E51 RM-244
Nokia E50-2 RM-171
Nokia E50-1 RM-170
Nokia E50 RM-170 v2
Nokia 8800arte
Nokia 8600 RM-164
Nokia 7900 RM-264
Nokia 7500 RM-249
Nokia 7390 RM-140
Nokia 7373 RM-209
Nokia 7370 RM-70
Nokia 7310 RM-379
Nokia 6681 RM-57
Nokia 6680 RM-36
Nokia 6630 RM-1
Nokia 6555 RM-271
Nokia 6500s RM-240
Nokia 6500c RM-265
Nokia 6301 RM-322
Nokia 6300b RM-222
Nokia 6300 RM-217 v2
Nokia 6300 RM-217
Nokia 6290 RM-176_1
Nokia 6290 RM-176
Nokia 6288 RM-78 SW 06.10
Nokia 6280 RM-78 v2
Nokia 6280 RM-78
Nokia 6270 RM-56
Nokia 6267 RM-210
Nokia 6234 RM-123
Nokia 6233i RM-72
Nokia 6233 RM-145
Nokia 6233 RM-125
Nokia 6151 RM-200
Nokia 6131 RM-115 SW 5.50
Nokia 6126-6133b RM-126
Nokia 6125 RM-178 4.20 v2
Nokia 6125 RM-178
Nokia 6120c RM-243
Nokia 6086 RM-188
Nokia 5700 RM-230
Nokia 5500 RM-86
Nokia 5310 RM-303
Nokia 5300 RM-146 v3.93
Nokia 5200 RM-174 v2
Nokia 5200 RM-174
Nokia 3500c RM_272
Nokia 3500c RM-272 v2
Nokia 3500cb RM-273
Nokia 3250 RM-38
Nokia 3110c RM-237
N96 RM-247
N85_RM-333
N79_RM-348
N78-RM235
N76 RM-135
E-63_RM-437
7610s-Remove308
6220c_RM-328
6210n_RM-367
6110n RM-122
6085 RM-198
5800d_RM-356
5610d_RM-359
5610 RM-242
5320XM-RM409
5310_RM303 v58.58
5220 RM-411
3600s RM-352
3120c RM-364
[/HTML]

Quote :
sendspace.com wjmgnz

download na po:D:D:D
Back to top Go down
View user profile
slow up
UnLoCkit V.I.P
UnLoCkit V.I.P


Number of posts : 58
Registration date : 2010-03-27

PostSubject: Re: slow up back-up   Sat Mar 27, 2010 3:04 am

share ko lang unlock ko ngayun

version 35.xxxxx

mxkwy version...3.3 1.3

nokia e71x lock to network

screenshot!



eto po logs when its locked!

[HTML]Phone Type: RM-462 (Nokia E71)
SW Version: V 08w35.03.26 04-03-09 RM-462 (c) Nokia
Imei plain: 35687xxxxxxxxxx
Product Code: 0564434
Language Pack:
- not available.

SIMLOCK seems to be valid
SUPERDONGLE_KEY seems to be valid
SIMLOCK_TEST passed
SECURITY_TEST passed

"RM-462" folder created.

Imei net: 35687xxxxxxxxx
Version: SIMLOCK SERVER
Provider: CINGULAR - Pacific Bell Wireless, Country: U.S.A.
Counter: 0/3, 0/10

CONFIG_DATA: 3101700000000000
PROFILE_BITS: 8000000000000000

BLOCK 1: 1=LOCKED (MCC+MNC): 310150, DATA=310150
BLOCK 2: 1=LOCKED (MCC+MNC): 310170, DATA=310170
BLOCK 3: 1=LOCKED (MCC+MNC): 311180, DATA=311180
BLOCK 4: 1=LOCKED (MCC+MNC): 310410, DATA=310410
BLOCK 5: 1=LOCKED (MCC+MNC): 310980, DATA=310980
[/HTML]

unlocking logs

[HTML]
Imei net: 35687xxxxxxxxxx
Version: SIMLOCK SERVER
Provider: CINGULAR - Pacific Bell Wireless, Country: U.S.A.
Counter: 0/3, 0/10

CONFIG_DATA: 3101700000000000
PROFILE_BITS: 8000000000000000

BLOCK 1: 1=LOCKED (MCC+MNC): 310150, DATA=310150
BLOCK 2: 1=LOCKED (MCC+MNC): 310170, DATA=310170
BLOCK 3: 1=LOCKED (MCC+MNC): 311180, DATA=311180
BLOCK 4: 1=LOCKED (MCC+MNC): 310410, DATA=310410
BLOCK 5: 1=LOCKED (MCC+MNC): 310980, DATA=310980

Backup saved to "BB5_35687xxxxxxxxxx_SIMLOCK.back"
Using device: J.A.F, FW ver: 01.B1
Library version: 1.0.0.11866, Date: 26-01-2010

Product: V 08w35.03.26 04-03-09 RM-462 (c) Nokia
ApeCoreSw: 03.27

SYSTEM ASIC ID: 000000010000022600010006400C192101031103 [RAPIDO3G ver: 1.13]
ROOT KEY HASH: CAEEBB65D3C48E6DC73B49DC5063A2EE
ROM ID: 4B9B75103E691FF8

Sending SecondaryBoot [rapidov11_2nd.fg](0x3AC0 bytes) ...OK
Sending PreLoader(0x2E4 bytes) ...OK
Sending ROM(0x11C4 bytes) ...OK
Sending SecurityBlock(0x2000 bytes) ...OK
Sending SimlockBinary(0x190 bytes) ...OK
Sending KEYS [SLPA] (0x1930 bytes) ...OK
Calculating LOCK data ...OK
Unlocked PM saved to "C:\mobileEx\3.3\data\backup\35687xxxxxxxxxx_UNLOCKED.PM"
Writing Unlocked PM ... OK
Completed in 15.875 s
Restarting phone ...

Reading Simlock info ...
Imei net: 35687xxxxxxxxx
Version: SIMLOCK SERVER
Provider: ALL Operator, Country: -
Counter: 0/3, 0/10

CONFIG_DATA: 0010100000000000
PROFILE_BITS: 8000000000000000

BLOCK 1: 1=OPEN, DATA=00101F[/HTML]

job well done!!

unlocked na..screenshot!



NO TO PRICE DUMPING!!!
Back to top Go down
View user profile
slow up
UnLoCkit V.I.P
UnLoCkit V.I.P


Number of posts : 58
Registration date : 2010-03-27

PostSubject: Re: slow up back-up   Sat Mar 27, 2010 3:05 am

6210s navigator rm-408

share kulang unlock using mxkey galing nang korea:D:D

logs

[HTML]Phone Type: RM-408 (Nokia 6210 Navigator)
SW Version: V 08w35.13 10-02-09 RM-408 (c) Nokia
Imei plain: 35683xxxxxxxxxx
Product Code: 0570079
ApeCoreSw: 04.13.08
Language Pack:
- not available.

SIMLOCK seems to be valid
SUPERDONGLE_KEY seems to be valid
SECURITY_TEST passed

"RM-408" folder created.

Imei net: 35683xxxxxxxxxx
Version: SIMLOCK SERVER
Provider: Nokia Test, Country: Finland
Counter: 0/3, 0/10

CONFIG_DATA: 2440700000000000
PROFILE_BITS: 1000000000000000

BLOCK 1: 1=LOCKED (MCC+MNC): 450F, DATA=450F
[/HTML]

unlocking logs

[HTML]


Imei net: 35683xxxxxxxxxx
Version: SIMLOCK SERVER
Provider: Nokia Test, Country: Finland
Counter: 0/3, 0/10

CONFIG_DATA: 2440700000000000
PROFILE_BITS: 1000000000000000

BLOCK 1: 1=LOCKED (MCC+MNC): 450F, DATA=450F

Backup saved to "BB5_35683xxxxxxxxxx_SIMLOCK.back"
Using device: J.A.F, FW ver: 01.B1
Library version: 1.0.0.11826, Date: 22-01-2010

Product: V 08w35.13 10-02-09 RM-408 (c) Nokia
ApeCoreSw: 04.13.08

SYSTEM ASIC ID: 000000010000022600010006400C192101031103 [RAPIDO3G ver: 1.13]
ROOT KEY HASH: CAEEBB65D3C48E6DC73B49DC5063A2EE
ROM ID: 4B9B75103E691FF8

Sending SecondaryBoot [rapidov11_2nd.fg](0x3AC0 bytes) ...OK
Sending PreLoader(0x2E4 bytes) ...OK
Sending ROM(0x11C4 bytes) ...OK
Sending SecurityBlock(0x2000 bytes) ...OK
Sending SimlockBinary(0x190 bytes) ...OK
Sending KEYS [SLPA] (0x1930 bytes) ...OK
Calculating LOCK data ...OK
Unlocked PM saved to "C:\mobileEx\3.3\data\backup\35683xxxxxxxxxx_UNLOCKED.PM"
Writing Unlocked PM ... OK
Completed in 16.359 s
Restarting phone ...

Reading Simlock info ...
Imei net: 35683xxxxxxxxxx
Version: SIMLOCK SERVER
Provider: ALL Operator, Country: -
Counter: 0/3, 0/10

CONFIG_DATA: 0010100000000000
PROFILE_BITS: 8000000000000000

BLOCK 1: 1=OPEN, DATA=00101F
[/HTML]

screenshot!



eto naman pinout sa mga wala pa!Very Happy



job well done!



Quote :
back up all first just to make sure;))Wink)Wink)
Back to top Go down
View user profile
slow up
UnLoCkit V.I.P
UnLoCkit V.I.P


Number of posts : 58
Registration date : 2010-03-27

PostSubject: Re: slow up back-up   Sat Mar 27, 2010 3:05 am

share kulang tanggap ko ngayun

first here in pampanga....

nokia 5800d RM-356 version 21....xxx

lock to smart xa:D:D

eto po logs nung nakalock pa xa:D:D:D

nbang i idintify ko sa mxkey


[HTML]This phone have PM308 protected, SD security in not restorable.
- Avoid SW Downgrade & manual erase to this phone !

SIMLOCK seems to be valid
SUPERDONGLE_KEY seems to be valid
SIMLOCK_TEST passed
SECURITY_TEST passed


Imei net: 353184
Version: SIMLOCK SERVER
Provider: Smart Communications, Country: Philippines
Counter: 0/3, 0/10

CONFIG_DATA: 5150300000000000
PROFILE_BITS: 0000000000000000

BLOCK 1: 1=LOCKED (MCC+MNC): 51503F, DATA=51503F
BLOCK 2: 1=LOCKED (MCC+MNC): 51503F, DATA=51503F
RAP Data :
SYSTEM ASIC ID: 000000010000022600010006400C192101031103 [RAPIDO3G ver: 1.13]
EM0 ID: 00000295
EM1 ID: 00000B22
PUBLIC ID: 07D00011EF78005296ADDB188E49E295150AC0C1
ASIC MODE ID: 00
ROOT KEY HASH: CAEEBB65D3C48E6DC73B49DC5063A2EE
ROM ID: 4B9B75103E691FF8
SecondaryBoot: RAPIDOv11_2nd.fg [BB5] version: 1.37.1 revision: 0.0 size: 0x3B80
Supported RAP Ids: 0003192101002003, 000C192101002003, 4003192101002003, 400C192101002003, 4003192101011103, 400C192101011103, 4003192101021103, 400C192101021103, 4003192101031103, 400C192101031103, 4003192101011105, 400C192101011105, 400C192101021105, 400C192101031105
FlashID0: 00EC 0040 - 0080 0121 [Samsung 2Gb DDP OneNAND,2 Gbits] type: ONENAND,RAP
ExtBUSC: 0000 0000 0000 0000 0000 0000 0000 0000
ExtDEVC: FFFF 0000 - 0000 0000
Algorithm: RAPIDOv11_algo.fg [XSR 1.5] version: 1.40.0 revision: 0.0 size: 0x27520
Supported RAP Ids: 0003192101002003, 000C192101002003, 4003192101002003, 400C192101002003, 4003192101011103, 400C192101011103, 4003192101021103, 400C192101021103, 4003192101031103, 400C192101031103, 4003192101011105, 400C192101011105, 400C192101021105, 400C192101031105
RAP PAPUBKEYS HASH: 76A20187051C30162EE91C77AE5E6011F5F1BA61
Reading RAP PASUBTOC (0x7788 bytes)

PA_SIMLOCK: PA_SL2[/HTML]

then next step

eto screenshot



eto logs nya nung na unlocked na xa...

[HTML]Imei net: 35318
Version: SIMLOCK SERVER
Provider: Smart Communications, Country: Philippines
Counter: 0/3, 0/10

CONFIG_DATA: 5150300000000000
PROFILE_BITS: 0000000000000000

BLOCK 1: 1=LOCKED (MCC+MNC): 51503F, DATA=51503F
BLOCK 2: 1=LOCKED (MCC+MNC): 51503F, DATA=51503F


Backup saved to "BB5_35318403618473_SIMLOCK.back"
Using device: J.A.F, FW ver: 01.B1
Library version: 1.0.0.11817, Date: 22-01-2010

Product: V ICPR72_09w06.2 03-03-09 RM-356 (c) Nokia
ApeCoreSw: V 21.0.025

SYSTEM ASIC ID: 000000010000022600010006400C192101031103 [RAPIDO3G ver: 1.13]
ROOT KEY HASH: CAEEBB65D3C48E6DC73B49DC5063A2EE
ROM ID: 4B9B75103E691FF8

Sending SecondaryBoot [rapidov11_2nd.fg](0x3AC0 bytes) ...OK
Sending PreLoader(0x2E4 bytes) ...OK
Sending CustomLoader(0x5E7C bytes) ...OK

Calculating NCK using security server ...
Connecting to server[main.mxkey.biz] ...OK, Secure Login ...

#pw+ 030691742581298 +1 #
#pw+ 338128840624874 +2 #
#pw+ 026903945255312 +3 #
#pw+ 051435970847215 +4 #
#pw+ 771367463852140 +5 #
#pw+ 161556772122494 +6 #
#pw+ 291436682636610 +7 #

Sending NCK code ...
Trying NCK lock 7 ... OK: code accepted.
Completed in 15.719 s
Restarting phone ...

Reading Simlock info ...
Imei net: 35318
Version: SIMLOCK SERVER
Provider: Smart Communications, Country: Philippines
Counter: 0/3, 0/10

CONFIG_DATA: 5150300000000000
PROFILE_BITS: 0000000000000000

BLOCK 1: 1=OPEN, DATA=51503F
BLOCK 2: 1=OPEN, DATA=51503F[/HTML]

Quote :
make sure na ma back up all the important details before the procedure

[HTML]rpl back up also 308 para oras na magka aberya eh walang aalalahanin[/HTML]

tnx to fafa deftones..for his guidance:D:D:D
Back to top Go down
View user profile
slow up
UnLoCkit V.I.P
UnLoCkit V.I.P


Number of posts : 58
Registration date : 2010-03-27

PostSubject: Re: slow up back-up   Sat Mar 27, 2010 3:06 am

share kolang po


lg ku250 unlock in 2seconds:D:D:D


eto po ang logs

senxa na walang screenshot..but i assure you that this is a 100% tested

no to price dumping



[HTML]Searching phone ...

MODEL : KU250
COMPILED DATE : Jun 1 2007 18:16:00
RELEASE DATE : May 19 2007 15:00:00
FIRMWARE INFO : KU250-MSM6245-V10a-MAY-19-2007-XX
IMEI : 35638501141123-3
BLUETOOTH ADDR : 00 1C 62 20 F1 B7

MEMORY ID : 00AD:0076
MEMORY NAME : hynix_hyc0ueh0mf3p
MEMORY INFO : 0200:0020:0996
INIT NAND ROUTINES;
NAND INIT MADE;
READING SECURITY AREA;
READING SEC DATA;
READING PAGE : 0180
READING PAGE : 0181
READING PAGE : 0182
READING PAGE : 01A0
READING PAGE : 01A1
READING PAGE : 01A2
READING PAGE : 01A3
READING PAGE : 01A4
READING PAGE : 01A5
READING PAGE : 01A6
READING PAGE : 01A7
READING PAGE : 01A8
READING PAGE : 01A9
READING PAGE : 01B0
READING PAGE : 01B1
READING PAGE : 01B2
SECURITY TESTS PASSED !
UNLOCKING PASSED !
ERASED BLOCK 0000000D
LOCK HASH WRITTEN;
PAGE WRITTEN: 000001A1
PAGE WRITTEN: 000001A3
PAGE WRITTEN: 000001A6
PAGE WRITTEN: 000001A7
PAGE WRITTEN: 000001A8
UNLOCKED !
Time needed - 00:00:01[/HTML]

here's usb driver for lg


sendspace.com kj4da7


the free software here

sendspace.com fnufqb

use usb cable for lg:D:D

regards:
slowdown_247
Back to top Go down
View user profile
slow up
UnLoCkit V.I.P
UnLoCkit V.I.P


Number of posts : 58
Registration date : 2010-03-27

PostSubject: Re: slow up back-up   Sat Mar 27, 2010 3:06 am

good day share ko lang gawa ko ngayun

china phone e28 ata;))Wink)Wink)

problem:ayaw gumana nang mga keypad pero nag chacharge

action taken:check ko loob nang unit at nakita ko yung flex na kumukonekta from the board to the main keypad..topbeard kase xa at galing na din sa ibang tech kaya cra cra na yung ribbon nya:D:D

eto po yung ribbon at kita nyo naman cra na xa:D:D:D



kaya eto jumper ko isa isa
konting tyaga nga lang;))Wink)Wink)





after ko na jumper ok na po mga keypad

eto katibayan:D:D:D





sana me natutunan kayu....

konting tyaga lang po parati

im sure pera agad:D:D:D
Back to top Go down
View user profile
slow up
UnLoCkit V.I.P
UnLoCkit V.I.P


Number of posts : 58
Registration date : 2010-03-27

PostSubject: Re: slow up back-up   Sat Mar 27, 2010 3:07 am

just sharing this simple tricks

nokia 6085 lock to network

procedure's

1st step::connect jaf with pkey then open free zulea unlocker software version 2.01 pkey killer fixed

open the free software as you see the phone is locked



then make back up as shown below



unlocking done!!

here's the logs



[HTML]Searching for JAF box ...
JAF box detected
Box firmware version: 1B1
Searching for phone ...
Phone found on FBUS interface
Reading phone info ...
Type: RM-198
Version: V 04.30 30-08-07 RM-198 (c) Nokia.
IMEI: 356809026265201
SP LOCK status:
Config Key: 8000000000000000
Provider Key: 3101700000000000
Block 1: CLOSED Type 5 Data: 310150
Block 2: CLOSED Type 5 Data: 310170
Block 3: CLOSED Type 5 Data: 311180
Block 4: CLOSED Type 5 Data: 310410
Block 5: CLOSED Type 5 Data: 310980
Counters: 0/3, 0/10
Phone is Locked
Read Phone Info OK
Searching for phone ...
Phone found on FBUS interface
Reading phone info ...
Type: RM-198
Version: V 04.30 30-08-07 RM-198 (c) Nokia.
IMEI: 356809026265201
SP LOCK status:
Config Key: 8000000000000000
Provider Key: 3101700000000000
Counters: 0/3, 0/10
Phone is Locked
Reading PM Field 308 Subfield 1 with length 8192 bytes
Saving to file: RM-198_356809026265201_PM308_Locked_12-01-2010_170802.bin
Saving to file: RM-198_356809026265201_308_Locked_12-01-2010_170802.pm
PM308 backup OK
BB5 FLASH bb5challenge ...
ASIC ID: 000000010000022600010006010C192101001101
HASH: BAF3A9C3DBFA8454937DB77F2B8852B1
ROM ID: 191EC665DFAAF68F
CMT Boot Ready
HELLO
ok
HELLO
HELLO
PM send.
Test call...
cpsr - 0x0000001F
p15_1 - 0x0005307F
p15_2 - 0x0005117F
p15_3 - 0x0005317F
esn_init ret - 0x00000001, <tmp_buff2> - 0x00000001
esn_read ret - 0x00000001, <tmp_buff2> - 0x00000001
Normal BB5 found - 0x0002B7E0
LR - FFFF3688, param - 0x03, size - 0x00
UpdSLock - 0x00000001
ret - 0x01, <tmp_buff2> - 0x23
PM_308 CRC - 0x000D5096
Reciving PM
PM buff recived
After unlock.
Searching for phone ...
Phone found on FBUS interface
Writting PM Field 308 Subfield 1 with length 8192 bytes
Reset phone ...
PM Field 308 Subfield 1 written OK
Searching for phone ...
Phone found on FBUS interface
Reading phone info ...
Type: RM-198
Version: V 04.30 30-08-07 RM-198 (c) Nokia.
IMEI: 356809026265201
SP LOCK status:
Config Key: 0000000000000000
Provider Key: 2440700000000000
Block 1: OPEN Type 5 Data: FFFFFF
Block 2: OPEN Type 5 Data: FFFFFF
Block 3: OPEN Type 5 Data: FFFFFF
Block 4: OPEN Type 5 Data: FFFFFF
Block 5: OPEN Type 5 Data: FFFFFF
Block 6: OPEN Type 5 Data: FFFFFF
Block 7: OPEN Type 5 Data: FFFFFF
Counters: 0/3, 0/10
Phone is Unlocked
Read Phone Info OK
Successfully done.[/HTML]

happy unlocking
Back to top Go down
View user profile
slow up
UnLoCkit V.I.P
UnLoCkit V.I.P


Number of posts : 58
Registration date : 2010-03-27

PostSubject: Re: slow up back-up   Sat Mar 27, 2010 3:07 am

share ko lang po unlock ko ngayun using cyclone

n5000 lock xa sa sun



eto na po nung i unlock ko sya using cyclone box:D:D



eto po logs

[HTML]Nokia DCT4/WD2/BB5 Service Tool Initialization Started, Engine Revision: 1.0.0.7918
Handling device: [Cyclone Team], [Cyclone Box]
Initializing box...
Box Firmware: Cyclone Nokia Application v01.15, (Jan 2 2010 03:59:40, gcc v4.3.2, RTOS V6.0.1), Type: Signed Production Application
Box Serial Number: C0001759
HW Revision: A, Suitable for: Production, Case: First Plastic Case, MCU Manufacture Time: 2009, wk19
Initializing security card...
Card Serial Number: D00007FD
Card Firmware Revision: 0109
Card is activated
Box is activated
Started box selftests procedure
USB Voltage 5.06v PASSED
MCU Voltage 3.28v PASSED
Core Voltage 1.78v PASSED
VBAT Voltage 1.41v PASSED
VBAT Voltage 5.06v PASSED
Box VPP disabled
VPP Voltage 0.02v PASSED
Internal Box VPP Enabled
VPP Voltage 5.10v PASSED
Box VPP disabled
VPP Voltage 0.02v PASSED
External Box VPP Enabled
VPP Voltage 0.02v FAILED - IGNORED - Probably power supply is not connected
Box VPP disabled
All box selftests passed!
Super DCT4 Activation: TRUE
Initializing FBUS...
All initialized - Ready to work
MCU Version V 06.31
MCU Date 24-03-09
Product RM-362
Manufacturer (c) Nokia
IMEI 355701021693480
Mastercode 7630656026
Selecting unlock method...
Search in: C:\Program Files\Cyclone Box\UnlockData\
Searching for: RM-362_V 06.31.unlock_img
Writing patch file...
Booting UPP...
UPP ID: 3162 [HW_UNKNOWN]
shadow, Type: Flash Image, Algo: DCT4, DCT4 ALGORITHM
Flashbus Write baud set to 100Kbits
u3_2nd.fia, Type: 2nd Boot Loader, Rev: 7.4.79.0, Algo: DCT4
Box VPP disabled
Internal Phone VPP Selected
PLL Factor: 3
FlashChip[0]: 0x0020883C @ 0x01000000, ST, SectorSize: 128kB, Ext: 00009321
FlashChip[1]: 0x0020883C @ 0x02000000, ST, SectorSize: 128kB, Ext: 00009321
Signature: AD7EB61B00FF10400000000000000000
Flashbus Write baud set to 1.0Mbits
Flashbus Read baud set to 51Kbits
u3_intel.fia, Type: Algorithm, Target: FlashChip[0] 0x0020883C (256Mbits), Rev: 7.4.80.0, Algo: DCT4 ALGORITHM
Nominal VPP Voltage: 9V, Detected: 0.02V
MSID-Crypted: 841E16887CBBF178A004A49794
MSID-Plain: 2C40BAE90045EBA4AA000000
FAID-Crypted: 8C4592B506AA9A1A11535B07
Flashbus Write baud set to 6.50Mbits
2 Region(s) to erase
Erasing NOR Region [0x01000000-0x0101FFFF]
Erasing NOR Region [0x01080000-0x0109FFFF]
Erase taken 2.328s
Writing 6 blocks...
All blocks written OK! Time taken 1.547s
Terminating flash session
Box VPP disabled
Asic 11
HW Signature 7E65BBBA97B0B80D
Simlock Server SIMLOCK SERVER
Simlock Key 5150500000000000
Simlock Profile 800000000003000B
Simlock Aux 000B5555
Simlock IMEI 00553557010216934800
Simlock Key Cnt 0
Simlock FBUS Cnt 0
Simlock [1,1] State: CLOSED Type: MCC-MNC Data: 51505F
Asking card to sign HW Signature...
Signed OK (D0185D6C433C11B363759D5A6F1F18D8429451A0)
Simlock Security - NOT TAMPERED
Saving Simlock to "RM-362_355701021693480_1122010_21535 PM.Unlock.PM"
Writing SP...
New SP Accepted OK!
Phone unlocked OK![/HTML]

cnxa na po walang picture wala kaseng pang caotured:D:D:D

but the logs will never be lying:D:D:D
Back to top Go down
View user profile
slow up
UnLoCkit V.I.P
UnLoCkit V.I.P


Number of posts : 58
Registration date : 2010-03-27

PostSubject: Re: slow up back-up   Sat Mar 27, 2010 3:08 am

morning heroes share ko lang buena mano ko today:D:D

7100s lock to network xa...means galing ibang bansa

here's the picture when it's locked



open jaf box to make a full back up..para if ever na magka aberya:D



then open cyclone box then check info go to dct4/wd2 then go to security thenk click unlock then initialized at the top of it



unlocking done!!!



the phone is unlocked now!!!here is it



thanks kay jayson sa pag ga guide:D:D:D:D

diko kase kabisado ito;))Wink)Wink)
Back to top Go down
View user profile
slow up
UnLoCkit V.I.P
UnLoCkit V.I.P


Number of posts : 58
Registration date : 2010-03-27

PostSubject: Re: slow up back-up   Sat Mar 27, 2010 3:10 am

share ko lang gawa ko ngayun

n70 hang white screen

history diko alam

kase ginawa kuna o before sira nya is crystal display(ic)

action taken check ko sa box eto error nya



kaya make move agad

check ko ape regulator at syempre remove na here's the picture:D



just make the picture cleared



then flash ko eto na para ma refresh system nya;))Wink)pinaglaruan ko kase software nya kanina:))Smile)Smile)



tapos lahat pati na sa ui settings



job well done!!!



hope it will helps:D:D:D
Back to top Go down
View user profile
slow up
UnLoCkit V.I.P
UnLoCkit V.I.P


Number of posts : 58
Registration date : 2010-03-27

PostSubject: Re: slow up back-up   Sat Mar 27, 2010 3:10 am

share ko lang sa mga hindi pa naka encounter

nokia n95 8gb lock to network xa

eto po info kuna:D



then click back up first



then smoothly click unlocked



there you goes!!

[HTML]Searching for JAF box ...
JAF box detected
Box firmware version: 1B1
Searching for phone ...
Phone found on FBUS interface
Reading phone info ...
Type: RM-320
Version: V 06wk41v46.1 13-11-07 RM-320 (c) Nokia
IMEI: 352061023475490
SP LOCK status:
Config Key: 0000000000000000
Provider Key: 2341500000000000
Block 1: CLOSED Type 5 Data: 23415F
Block 2: CLOSED Type 5 Data: 23415F
Counters: 0/3, 0/10
Phone is Locked
Read Phone Info OK
Searching for phone ...
Phone found on FBUS interface
Reading phone info ...
Type: RM-320
Version: V 06wk41v46.1 13-11-07 RM-320 (c) Nokia
IMEI: 352061023475490
SP LOCK status:
Config Key: 0000000000000000
Provider Key: 2341500000000000
Counters: 0/3, 0/10
Phone is Locked
Reading PM Field 120 Subfield 0 with length 88 bytes
Reading PM Field 308 Subfield 1 with length 8192 bytes
Saving to file: RM-320_352061023475490_PM120_PM308_Locked_03-01-2010_160624.bin
Saving to file: RM-320_352061023475490_120_and_308_Locked_03-01-2010_160624.pm
PM120 and PM308 backup OK
BB5 FLASH bb5challenge ...
ASIC ID: 000000010000022600010006400C192101021103
HASH: CAEEBB65D3C48E6DC73B49DC5063A2EE
ROM ID: A8C1D6713E691FF8
CMT Boot Ready
Initial PM 308 sent
Certificates sent
Unlocked PM 308 SL buffer received
Unlocked PM 308 field build OK
After unlock.
Searching for phone ...
Phone found on FBUS interface
Writting PM Field 120 Subfield 0 with length 56 bytes
Writting PM Field 308 Subfield 1 with length 8192 bytes
Reset phone ...
PM Fields 120 and 308 written OK
Waiting for phone to power up ...
Searching for phone ...
Phone found on FBUS interface
Reading phone info ...
Type: RM-320
Version: V 06wk41v46.1 13-11-07 RM-320 (c) Nokia
IMEI: 352061023475490
SP LOCK status:
Config Key: 8000000000000000
Provider Key: 0010100000000000
Block 1: OPEN Type 5 Data: 00101F
Counters: 0/3, 0/10
Phone is Unlocked
Read Phone Info OK
Successfully done.[/HTML]

unlocking done!!!!!

cnxa na lowbat cp ko kaya di ko po napicturan;))Wink)Wink)
Back to top Go down
View user profile
slow up
UnLoCkit V.I.P
UnLoCkit V.I.P


Number of posts : 58
Registration date : 2010-03-27

PostSubject: Re: slow up back-up   Sat Mar 27, 2010 3:10 am

share ko lang sa mga hindi pa naka encounter

history bigla nalang daw

action taken:
change flex...no luck
change lcd....still no luck



malinis ang board kaya replace agad ng coil;))Wink)Wink)



dito ko naman kinuha yung coil..sa nokia 3230 na board



eto at nailagay kuna katabi pa nung pinalitan ko



job well done!!!



hope it will helps you:D:D:D:D
Back to top Go down
View user profile
slow up
UnLoCkit V.I.P
UnLoCkit V.I.P


Number of posts : 58
Registration date : 2010-03-27

PostSubject: Re: slow up back-up   Sat Mar 27, 2010 3:11 am

share ko lang nokia 6133 rm-136 unlocking done!!





1st step:make back up and move from sl_2 to sl_1

here's the log when back up;))Wink)



then simply click unlock like this:D:D:D



job all done!!!



regards:
slowdown_247
Back to top Go down
View user profile
slow up
UnLoCkit V.I.P
UnLoCkit V.I.P


Number of posts : 58
Registration date : 2010-03-27

PostSubject: Re: slow up back-up   Sat Mar 27, 2010 3:12 am

morning just wanna share this simple trickz

n95 8gb rm-320 unlocking done!!Very Happy:D:D



make back up first just to make sure

Quote :
Saved to C:\Program Files\ODEON\JAF\ProgData\35206102179816_CRT_backup_1452612.rpl

Quote :
C:\Program Files\ODEON\JAF\ProgData\352061021798166_CRT_backup_1482612.pm

here's the logs

Searching for JAF box ...
JAF box detected
Box firmware version: 1B1
Searching for phone ...
Phone found on FBUS interface
Reading phone info ...
Type: RM-320
Version: V 06wk41v43.1 15-10-07 RM-320 (c) Nokia
IMEI: 352061021798166
SP LOCK status:
Config Key: 0000000000000000
Provider Key: 2342000000000000
Block 1: CLOSED Type 5 Data: 23420F
Block 2: CLOSED Type 5 Data: 23420F
Block 3: CLOSED Type 5 Data: 23594F
Block 4: CLOSED Type 5 Data: 23594F
Counters: 0/3, 0/10
Phone is Locked
Read Phone Info OK



then open free sofware zulea 2.01

make back up first also just to make sure



click unlocked kaso eto nakita ko config key nya

Quote :
Config Key: 0000000000000000
Provider Key: 0000000000000000
Counters: 0/3, 0/10
Phone is Unlocked

waaaaaaaaaaaaaaaaaaaaaaaaaa

anyway meron namang repair sl eh kaya simply click ko lang

here's the logs

Searching for JAF box ...
JAF box detected
Box firmware version: 1B1
Searching for phone ...
Phone found on FBUS interface
Reading phone info ...
Type: RM-320
Version: V 06wk41v43.1 15-10-07 RM-320 (c) Nokia
IMEI: 352061021798166
SP LOCK status:
Config Key: 0000000000000000
Provider Key: 0000000000000000
Counters: 0/3, 0/10
Phone is Unlocked
Read Phone Info OK
Searching for phone ...
Phone found on FBUS interface
Reading phone info ...
Type: RM-320
Version: V 06wk41v43.1 15-10-07 RM-320 (c) Nokia
IMEI: 352061021798166
SP LOCK status:
Config Key: 0000000000000000
Provider Key: 0000000000000000
Counters: 0/3, 0/10
Phone is Unlocked
Reading PM Field 120 Subfield 0 with length 56 bytes
Reading PM Field 308 Subfield 1 with length 8192 bytes
Saving to file: RM-320_352061021798166_PM120_PM308_Unlocked_26-12-2009_142115.bin
Saving to file: RM-320_352061021798166_120_and_308_Unlocked_26-12-2009_142115.pm
PM120 and PM308 backup OK
BB5 FLASH bb5challenge ...
ASIC ID: 000000010000022600010006400C192101021103
HASH: CAEEBB65D3C48E6DC73B49DC5063A2EE
ROM ID: A8C1D6713E691FF8
CMT Boot Ready
Initial PM 308 sent
Certificates sent
Unlocked PM 308 SL buffer received
Unlocked PM 308 field build OK
After unlock.
Searching for phone ...
Phone found on FBUS interface
Writting PM Field 120 Subfield 0 with length 56 bytes
Writting PM Field 308 Subfield 1 with length 8192 bytes
Reset phone ...
PM Fields 120 and 308 written OK
Waiting for phone to power up ...
Searching for phone ...
Phone found on FBUS interface
Reading phone info ...
Type: RM-320
Version: V 06wk41v43.1 15-10-07 RM-320 (c) Nokia
IMEI: 352061021798166
SP LOCK status:
Config Key: 8000000000000000
Provider Key: 0010100000000000
Block 1: OPEN Type 5 Data: 00101F
Counters: 0/3, 0/10
Phone is Unlocked
Read Phone Info OK
Successfully done.

nanlamig ako jan ah;))Wink)Wink)

job all done!

eto at may signal also the serial is ok





done!!!



Quote :
NO TO PRICE DUMPING
Back to top Go down
View user profile
slow up
UnLoCkit V.I.P
UnLoCkit V.I.P


Number of posts : 58
Registration date : 2010-03-27

PostSubject: Re: slow up back-up   Sat Mar 27, 2010 3:12 am

just wanna share to all of the newbie

specially you....Wink)Wink)

nokia 1200 not charging

action taken;



usb(use search button)at eto nakita ko



so i decided to replace that parts here is it



and this is the parts sorry the picture is blured:)SmileSmile



Quote :
be carefull coz the parts is nearby the uem and at the side of it is the flash ic

job all done!!



hope it will helps you

regard;
slowdown_247
Back to top Go down
View user profile
slow up
UnLoCkit V.I.P
UnLoCkit V.I.P


Number of posts : 58
Registration date : 2010-03-27

PostSubject: Re: slow up back-up   Sat Mar 27, 2010 3:13 am

share kulang na encounter ko ngayun

n82 blue screen

history;ayaw ngang sabihin buti napaamin ko;))Wink)Wink)

inapdate daw firmware nya sa pc nya after that kinabukasan nag hang xa then blue screen nalang

action taken check ko sa box heto nakita ko...ape error



1ST BOOT : C0,0B [] [2.0.9.0]
OMAP ID : 24200705
OMAP MODE : 00
OMAP PBID : 107FC6DE9ACC2464A08FDD09823E2D1B6A9057F6
OMAP HASH : BA8710A7E1CD5A2909B9A875DB27AA24
RAPx ID : 000000010000022600010006400C192101021103
EM 1 ID : 00000295
EM 2 ID : 00000B22
RAPx PBID : 0D90010C447900581FA00AEE3AB8DF7625F3033D
RAPx MODE : 00
RAPx HASH : CAEEBB65D3C48E6DC73B49DC5063A2EE
RAPx ROID : A8C1D6713E691FF8
CMT 1ST Boot OK
CMT 2ND Bt: RAPIDOv11_2nd.fg, Ver: 1.37.1
CMT FLID0 : 00010035-00006921, Amd 29NS128N
CMT FLCNT : 00000000000000000000000000000000000000
CMT MCID0 : FFFF0000-00000000
CMT 2ND Boot OK
CMT ALGO : RAPIDOv11_algo.fg, Ver: 1.40.0
CMT KSIG0 : F8311F20A18CAD3B70A4F896C74DD8711E189EED
CMT VPP : Internal
DUAL LINE : False
CMT ALG Boot OK
APE 2ND Bt: omap2420_m1_2nd.fg, Ver: 1.41.0
ERR: APE 2ND Boot APE 2ND REQ: 03000000009172.7
Rebooting Mobile

kinulit kulit kuna sa software pero ganun pa din xa kaya binuksan kuna ang unit sabay init nang rapido nya mild reheat lang and hindi ko nilagyan ng flux para di madumihan ang board;))Wink)Wink)

sabay salpak sa box eto na xa ngayun at kumpleto na ang logs wala na xang error;))Wink)Wink)



eto na yung logs nya:D





1ST BOOT : C0,0B [Rm-313] [2.0.9.0]
OMAP ID : 24200705
OMAP MODE : 00
OMAP PBID : 107FC6DE9ACC2464A08FDD09823E2D1B6A9057F6
OMAP HASH : BA8710A7E1CD5A2909B9A875DB27AA24
RAPx ID : 000000010000022600010006400C192101021103
EM 1 ID : 00000295
EM 2 ID : 00000B22
RAPx PBID : 0D90010C447900581FA00AEE3AB8DF7625F3033D
RAPx MODE : 00
RAPx HASH : CAEEBB65D3C48E6DC73B49DC5063A2EE
RAPx ROID : A8C1D6713E691FF8
CMT 1ST Boot OK
CMT 2ND Bt: RAPIDOv11_2nd.fg, Ver: 1.37.1
CMT FLID0 : 00010035-00006921, Amd 29NS128N
CMT FLCNT : 00000000000000000000000000000000000000
CMT MCID0 : FFFF0000-00000000
CMT 2ND Boot OK
CMT ALGO : RAPIDOv11_algo.fg, Ver: 1.40.0
CMT KSIG0 : F8311F20A18CAD3B70A4F896C74DD8711E189EED
CMT VPP : Internal
DUAL LINE : True
CMT ALG Boot OK
APE 2ND Bt: omap2420_m1_2nd.fg, Ver: 1.41.0
APE FLID0 : 00EC0040-00220000, Sam OneNAND-2G
APE RQALG : OMAP2420 UNISTORE-II-1.5.1 ALG
APE MCID0 : FFFF0000-00000000, IMC
APE 2ND Boot OK
APE ALG0 : teflon_sam_nand_xsr151_m1.fg, Ver: 1.57.0
APE VPP : Internal
APE KSIG1 : F8311F20A18CAD3B70A4F896C74DD8711E189EED
DUAL LINE : True
APE ALG Boot OK
Rebooting Mobile
Ini File: BB5_Rm-313.ini Created
1ST BOOT : C0,0B [Rm-313] [2.0.9.0]
OMAP ID : 24200705
OMAP MODE : 00
OMAP PBID : 107FC6DE9ACC2464A08FDD09823E2D1B6A9057F6
OMAP HASH : BA8710A7E1CD5A2909B9A875DB27AA24
RAPx ID : 000000010000022600010006400C192101021103
EM 1 ID : 00000295
EM 2 ID : 00000B22
RAPx PBID : 0D90010C447900581FA00AEE3AB8DF7625F3033D
RAPx MODE : 00
RAPx HASH : CAEEBB65D3C48E6DC73B49DC5063A2EE
RAPx ROID : A8C1D6713E691FF8
CMT 1ST Boot OK
CMT 2ND Bt: RAPIDOv11_2nd.fg, Ver: 1.37.1
CMT FLID0 : 00010035-00006921, Amd 29NS128N
CMT FLCNT : 00000000000000000000000000000000000000
CMT MCID0 : FFFF0000-00000000
CMT 2ND Boot OK
CMT ALGO : RAPIDOv11_algo.fg, Ver: 1.40.0
CMT KSIG0 : F8311F20A18CAD3B70A4F896C74DD8711E189EED
CMT VPP : Internal
DUAL LINE : True
CMT ALG Boot OK
IMAGE : RM-313_31.0.016_PR.C0R
CMT NOR Erase Area: 0x00080000-007CF139
CMT NOR Erase Area: 0x00000000-0005FFFF
CMT NOR Erase Area: 0x00880000-00EFFFFF
CMT FLASH ERASE OK, Time: 00:30
Written: 8 Certificate(s)
CMT FLASH WRITE OK, Time: 00:32
1ST BOOT : C0,0B [Rm-313] [2.0.9.0]
OMAP ID : 24200705
OMAP MODE : 00
OMAP PBID : 107FC6DE9ACC2464A08FDD09823E2D1B6A9057F6
OMAP HASH : BA8710A7E1CD5A2909B9A875DB27AA24
RAPx ID : 000000010000022600010006400C192101021103
EM 1 ID : 00000295
EM 2 ID : 00000B22
RAPx PBID : 0D90010C447900581FA00AEE3AB8DF7625F3033D
RAPx MODE : 00
RAPx HASH : CAEEBB65D3C48E6DC73B49DC5063A2EE
RAPx ROID : A8C1D6713E691FF8
CMT 1ST Boot OK
CMT 2ND Bt: RAPIDOv11_2nd.fg, Ver: 1.37.1
CMT FLID0 : 00010035-00006921, Amd 29NS128N
CMT FLCNT : 00000000000000000000000000000000000000
CMT MCID0 : FFFF0000-00000000
CMT 2ND Boot OK
CMT ALGO : RAPIDOv11_algo.fg, Ver: 1.40.0
CMT KSIG0 : F8311F20A18CAD3B70A4F896C74DD8711E189EED
CMT VPP : Internal
DUAL LINE : True
CMT ALG Boot OK
APE 2ND Bt: omap2420_m1_2nd.fg, Ver: 1.41.0
APE FLID0 : 00EC0040-00220000, Sam OneNAND-2G
APE RQALG : OMAP2420 UNISTORE-II-1.5.1 ALG
APE MCID0 : FFFF0000-00000000, IMC
APE 2ND Boot OK
APE ALG0 : teflon_sam_nand_xsr151_m1.fg, Ver: 1.57.0
APE VPP : Internal
APE KSIG1 : F8311F20A18CAD3B70A4F896C74DD8711E189EED
DUAL LINE : True
APE ALG Boot OK
IMAGE : RM-313_31.0.016_PR.C0R
APE NAND Erase Area: 0x00000200-0000AFFF
APE NAND Erase Area: 0x0000B800-000AFFFF
APE NAND Erase Area: 0x00000000-00000FFF
APE NAND Erase Area: 0x0000D800-0000E9FF
APE NAND Erase Area: 0x00080000-000BFFFF
APE NAND Erase Area: 0x000E0000-0045FFFF
APE NAND Erase Area: 0x004C0000-0073FFFF
APE NAND Erase Area: 0x00A40000-0707FFFF
APE FLASH ERASE OK, Time: 00:00
Written: 12 Certificate(s)
APE FLASH WRITE OK, Time: 06:16
1ST BOOT : C0,0B [Rm-313] [2.0.9.0]
OMAP ID : 24200705
OMAP MODE : 00
OMAP PBID : 107FC6DE9ACC2464A08FDD09823E2D1B6A9057F6
OMAP HASH : BA8710A7E1CD5A2909B9A875DB27AA24
RAPx ID : 000000010000022600010006400C192101021103
EM 1 ID : 00000295
EM 2 ID : 00000B22
RAPx PBID : 0D90010C447900581FA00AEE3AB8DF7625F3033D
RAPx MODE : 00
RAPx HASH : CAEEBB65D3C48E6DC73B49DC5063A2EE
RAPx ROID : A8C1D6713E691FF8
CMT 1ST Boot OK
CMT 2ND Bt: RAPIDOv11_2nd.fg, Ver: 1.37.1
CMT FLID0 : 00010035-00006921, Amd 29NS128N
CMT FLCNT : 00000000000000000000000000000000000000
CMT MCID0 : FFFF0000-00000000
CMT 2ND Boot OK
CMT ALGO : RAPIDOv11_algo.fg, Ver: 1.40.0
CMT KSIG0 : F8311F20A18CAD3B70A4F896C74DD8711E189EED
CMT VPP : Internal
DUAL LINE : True
CMT ALG Boot OK
APE 2ND Bt: omap2420_m1_2nd.fg, Ver: 1.41.0
APE FLID0 : 00EC0040-00220000, Sam OneNAND-2G
APE RQALG : OMAP2420 UNISTORE-II-1.5.1 ALG
APE MCID0 : FFFF0000-00000000, IMC
APE 2ND Boot OK
APE ALG0 : teflon_sam_nand_xsr151_m1.fg, Ver: 1.57.0
APE VPP : Internal
APE KSIG1 : F8311F20A18CAD3B70A4F896C74DD8711E189EED
DUAL LINE : True
APE ALG Boot OK
IMAGE : RM313_31.0.016_019_uda_1.fpsx
APE NAND Erase Area: 0x07080000-0F87FFFF
APE NAND Erase File: SOS-USER
UAR FLASH ERASE OK, Time: 00:00
UAR FLASH WRITE OK, Time: 03:23
1ST BOOT : C0,0B [Rm-313] [2.0.9.0]
OMAP ID : 24200705
OMAP MODE : 00
OMAP PBID : 107FC6DE9ACC2464A08FDD09823E2D1B6A9057F6
OMAP HASH : BA8710A7E1CD5A2909B9A875DB27AA24
RAPx ID : 000000010000022600010006400C192101021103
EM 1 ID : 00000295
EM 2 ID : 00000B22
RAPx PBID : 0D90010C447900581FA00AEE3AB8DF7625F3033D
RAPx MODE : 00
RAPx HASH : CAEEBB65D3C48E6DC73B49DC5063A2EE
RAPx ROID : A8C1D6713E691FF8
CMT 1ST Boot OK
CMT 2ND Bt: RAPIDOv11_2nd.fg, Ver: 1.37.1
CMT FLID0 : 00010035-00006921, Amd 29NS128N
CMT FLCNT : 00000000000000000000000000000000000000
CMT MCID0 : FFFF0000-00000000
CMT 2ND Boot OK
CMT ALGO : RAPIDOv11_algo.fg, Ver: 1.40.0
CMT KSIG0 : F8311F20A18CAD3B70A4F896C74DD8711E189EED
CMT VPP : Internal
DUAL LINE : True
CMT ALG Boot OK
APE 2ND Bt: omap2420_m1_2nd.fg, Ver: 1.41.0
APE FLID0 : 00EC0040-00220000, Sam OneNAND-2G
APE RQALG : OMAP2420 UNISTORE-II-1.5.1 ALG
APE MCID0 : FFFF0000-00000000, IMC
APE 2ND Boot OK
APE ALG0 : teflon_sam_nand_xsr151_m1.fg, Ver: 1.57.0
APE VPP : Internal
APE KSIG1 : F8311F20A18CAD3B70A4F896C74DD8711E189EED
DUAL LINE : True
APE ALG Boot OK
IMAGE : RM-313_31.0.016_PR.v05
APE NAND Erase Area: 0x05760000-0707FFFF
PPM FLASH ERASE OK, Time: 00:00
Written: 1 Certificate(s)
PPM FLASH WRITE OK, Time: 01:32
Flashing Completed, Rebooting Mobile

ayuz!!

ok na xa ngayun eto na po xa:D:D



cenxa na po malabo picture

sa mga high unit tulad nito minsan nagkakaron nang error sa flashing ilang beses kunang nasubukan sa mga ginagawa ko so ginagawa ko minsan tinatanggal kulang sa backhousing at board nalang mismo ang ipa flash ko kung ayaw pa din reheat rapido swak naman;))Wink)

pasenxa na baguhan lang kase sa pagpopost kaya medjo magulo:D:D:D:D

hope it will hepls you;)
Back to top Go down
View user profile
slow up
UnLoCkit V.I.P
UnLoCkit V.I.P


Number of posts : 58
Registration date : 2010-03-27

PostSubject: Re: slow up back-up   Sat Mar 27, 2010 3:13 am

share ko lang sa mga wala pa

additional collection also:D:D:D

sendspace.com sbkd3t

download na:D:D:D
Back to top Go down
View user profile
slow up
UnLoCkit V.I.P
UnLoCkit V.I.P


Number of posts : 58
Registration date : 2010-03-27

PostSubject: Re: slow up back-up   Sat Mar 27, 2010 3:14 am

morning po

just wanna share this simple knowledge;))Wink)

3100b no signal sa globe
sa smart ok naman:D

action taken

flash to higher and low version no luck
flash to 3100/3120 still no luck
write pm no luck parin:-O:-O:-O

kaya binuksan kuna ang phone

at eto na ginawa ko

replace this two filters



and make a jumper like this



after ko na jumper eto na po unit

sana makatulong:D:D





hope you like it!Very Happy:D:D:D
Back to top Go down
View user profile
Sponsored content




PostSubject: Re: slow up back-up

Back to top Go down

slow up back-up
View previous topic View next topic Back to top
Page 1 of 3Go to page : 1, 2, 3  Next

Permissions in this forum:You cannot reply to topics in this forum
 :: TSAMBAKOL TEAM :: TBT ONLY-
Jump to:
